1 INTRODUCTION
1.1 General Description
SQ909B-L is an economic backend designed for Digital Video Camera (DVC) applications. It supports CMOS sensors up to 3MP and OLED / CSTN / TFT panel interfaces. The processor provides all essential functions, including image processing to optimize the captured images/videos and playback in full screen with high performance. With the motion JPEG technology, the SQ909B-L can record continuous stream live video to VGAQVGA resolution as a Digital Video Camcorder (DVC). Moreover, the SQ909B-L can perform as a Digital Camera to support still image up to 3MP resolution with innovative technology, including higher boot-up and shot-to-shot speed, and supports 3-layer image overlap and 2D graphic based OSD. For audio applications, SQ909B-L also includes internal audio DACIADC with 12bit resolution. In data storage, SQ909B-L supports both SLC/MLC NAND flash(1) and SD/SDHC/MMC cards storage up to 16GB, and can be as a mass storage connecting to PC via USB 2.0. Best of all, SQ909B provides a tun-key solution for developers and manufacturers targeting at versatile DVCs.
1.2Features
※ Image Capture and Processing
⚫ Support digital scaling and interpolation
⚫ Offset bias (OB)
⚫ Global gain
⚫ Color gain
⚫ Programmable gamma table
⚫ Saturation/Brightness adjüstment
⚫ Contrast adjustment
⚫ De-noise
⚫ Edge enhancement
⚫ Gb/Gr balance
⚫ Programmable auto exposure windows
⚫ Programmable auto white balance source
⚫ Color correction
⚫ Lens uniformity compensation
⚫ Dynamic defect pixel compensation
⚫ Static defect pixel compensation
⚫ Back light compensation
⚫ False color suppression
⚫ Real time image merge function for Photo ticker, Photo time/date stamp
⚫ Support 3-layer image overlap
⚫ Up to 64X smooth digital zoom
⚫ Support dynamic zoom for both preview and record
※ Display
⚫ Interface to OLED / CSTN / TFT panel
⚫ 2D multi-color graphic-based OSD
⚫ Support CCIR output
※ Compression
⚫ Standard M-JPEG CODEC
⚫ AVI Record up to 30fps@ VGA/QVGA
⚫ Embedded TV encoder for both NTSC and PAL
⚫ Programmable JPEG quantization table
※ Storage
⚫ Support SPI flash for code storage
⚫ Support SLC/MLC NAND flash(1) memory
⚫ Support SD/SDHC/MMC memory cards
※ Audio
⚫ On-Chip 12bit DAC for ext. speaker
⚫ On-Chip 12bit ADC for ext. microphone
※ CPU and Memory
⚫ Support SPI/NAND flash boot up
⚫ Support SDRAM of 16(2)/64/128/256Mbit with 16-bit interface
⚫ 4 general timers and 1 set watchdog timer
⚫ In-system-programming for firmware update from USB or Memory cards
⚫ CPU operating frequency up to 120MHz
※ Peripherals
⚫ Support IGBT/SCR strobe light
⚫ Support SPI I/F
⚫ Support master/slave mode IlC IF
⚫ 4CH peripheral ADC (Voltage Detector)
⚫ Low-power built-in Real Time Clock (RTC)
⚫ 1 setUART port
⚫ 4CH PWM
⚫ 16 GPIOs
※ USB Connection
⚫ Compliant with USB 2.0 FS Spec.
⚫ Support MSDC (Mass Storage)
⚫ Support P-CAM
⚫ Support Picture Bridge
⚫ Support Auto-Run
※ Package and Power
⚫ Core: 1.8V
⚫ I/O: 3.3V
⚫ SQ909B-L: LQFP128 (RoHS)
⚫ SQ909B-D: COB (RoHS)
(1) An extra control IC is needed to support MLC NAND Flash.
(2) Only basic DSC/DV functions supported in 1Mbit x16 system. Service & Quality Technology All Rights Reserved. P 2/13Rev 1.2-Mar. 18h, 2010
1 介绍
1.1 总体描述
SQ909B-L是为数字视频摄像机(DVC)应用而设计的经济后端。它支持高达3MP的CMOS传感器和OLED / CSTN / TFT面板接口。处理器提供了所有的基本功能，包括图像处理，以优化捕获的图像/视频和全屏播放高性能。采用动态JPEG技术，SQ909B可以作为数字视频摄像机(DVC)，以VGA QVGA分辨率录制连续流实时视频。此外，SQ909B-L还可以作为数码相机使用创新技术，支持高达300万像素的静态图像，包括更高的启动速度和镜头对镜头的速度，并支持3层图像重叠和基于2D图形的OSD。对于音频应用程序，SQ909B-L还包括12位分辨率的内部音频DACIADC。在数据存储方面，SQ909B-L支持SLC/MLC NAND flash(1)和SD/SDHC/MMC卡存储，最高可达16GB，并可通过USB 2.0连接到PC作为大容量存储。最重要的是，SQ909B-L为针对多功能dvc的开发人员和制造商提供了一个统一密钥解决方案。
1.2特性
※ 图像采集与处理
⚫支持数字缩放和插值
⚫偏移偏置(OB)
⚫全球获得
⚫颜色获得
⚫可编程伽马表
⚫饱和度和亮度调整
⚫对比度调整
⚫消除噪音
⚫边缘增强
⚫Gb / Gr的平衡
⚫可编程自动曝光窗口
⚫可编程自动白平衡源
⚫色彩校正
⚫透镜均匀性补偿
⚫动态缺陷像素补偿
⚫静态缺陷像素补偿
⚫背光补偿
⚫假色抑制
⚫实时图像合并功能的照片ticker，照片时间/日期戳
⚫支持3层图像重叠
⚫高达64X平滑数码变焦
⚫支持动态缩放预览和记录
※ 显示、
⚫OLED / CSTN / TFT面板接口
⚫基于2D多色图形的OSD
⚫支持CCIR输出
※ 压缩
⚫标准M-JPEG编解码
⚫AVI记录高达30fps@ VGA/QVGA
⚫嵌入式电视编码器的NTSC和PAL
⚫可编程JPEG量化表
※ 存储
⚫支持SPI flash代码存储
⚫支持SLC/MLC NAND flash(1)内存
⚫支持SD/SDHC/MMC存储卡
※ 音频
⚫用于外接扬声器的片上12位DAC
⚫用于外接麦克风的片上12位ADC
※ CPU和内存
⚫支持SPI/NAND flash启动
⚫支持16(2)/64/128/256Mbit的16位接口SDRAM
⚫4个通用定时器和1个设置看门狗定时器
⚫在系统编程固件更新从USB或记忆卡
⚫CPU工作频率:120MHz
※ 外围设备
⚫支持IGBT/SCR频闪灯
⚫支持SPI I/F
⚫支持主/从模式IIC I/F
⚫4通道外围ADC(电压检测器)
⚫低功耗内置实时时钟(RTC)
⚫1 set UART端口
⚫4 ch PWM
⚫16 GPIOs
※ USB连接
⚫兼容usb2.0 FS规范。
⚫支持MSDC(海量存储)
⚫支持P-CAM
⚫支撑图片桥
⚫支持自动运行
※ 封装和电源
⚫核心:1.8 v
⚫I / O: 3.3 v
⚫SQ909B-L: LQFP128 (RoHS)
⚫SQ909B-D: COB (RoHS)
(1)需要额外的控制IC来支持MLC NAND Flash。
(2) 1Mbit x16系统仅支持基本的DSC/DV功能。版权所有P 2/13Rev 1.2 3月。18 h, 2010
